Design Gateway, the leading provider of Altera (Intel)lectual Property (IP) cores for data storage, networking and FPGA-accelerated computing, is selected as a member of AMD’s VAR Founders Club and offers high performance computing solutions based on AMD’s Alveo Cards.

AMD's Alveo Card delivers significant performance advantages in key data center workloads, including Computational Storage, Database and Data Analytics, Financial Technology, High Performance Computing, Network Acceleration, Video Analytics and Artificial Altera (Intel)ligence (AI).

The Alveo Card's reprogrammed capability also increases adaptability and flexibility as workloads evolve, unlike fixed function accelerator cards.

Product Lineup


Alveo V70
Alveo U25
Alveo U50
Alveo U250

Document download

Document name
Presentation : IP Cores & Solutions for FPGA Accelerator
Product Leaflet : Alveo Card
Getting Started with Turnkey Accelerator Systems TKAS-D2101

Avilable Demos on Alveo Accelerator card

Devices Alveo U250, Alveo U50
IP core Demo Reference Design Document Demo Instruction Document FPGA Board Setup Free Evaluation demo file
(Ask password)
LLNetwork-IP
LL Network IP		 Accelerated Algorithmic Trading (AAT) Demo Rev2.0 Rev1.1 U250
U50
LLNetwork-IP
LL 10G EMAC IP		 Accelerated Algorithmic Trading (AAT) Demo Rev1.0 Rev1.1 U250
U50
TOE100G-IP
TOE100G-IP
 DMA Demo Rev1.0 Rev1.0 Rev1.0 U250
U50
NVMeTCP-IP NVMeTCP25G-IP 4ch Demo Rev1.0 Rev1.0 U50

4 x NVMeTCP25G Demo

Design Gateway provide 4 x NVMeTCP25G reference design on Alveo Card to fully utilize 100GbE (25G x 4) Ethernet interface port on Alveo Card and demonstrate NVMe/TCP Host performance on Alveo Card with NVMeTCP Target.

Each NVMeTCP connection performance can achieve 2GB/s or more depended on NVMeTCP Target. This reference design is available for NVMeTCP25G core customer for evaluation and shorten your development time.

Full 100G TCP offload by TOE100G-IP

TCP transmission at 100G speed is a compute-intensive workload for CPUs and it is difficult to achieve high sustained throughput without hardware accelerator.

TOE100G-IP Core is designed to fully offload TCP transmission from CPU by pure hardware logic. Our demo application on Alveo Card can achieve nearly 100G throughput with minimal CPU usage.

YouTube Video Series

Product Introduction
[EP0]		 System Setup & Validation
[EP1]
DG LL 10G EMAC-IP with AMD’s AAT demo
[EP2]		 GZIP Compression demo
[EP3]
Gzip demo on Alveo

Blogs

Design Gateway's Technology Blog: Turnkey Accelerator Systems

Turnkey Accelerator system

TKAS-D2101 Specification

  • Altera (Intel) Core i7 Processor with Deep Learning Boost AI acceleration and AVX-512 instruction set
  • DDR4 3200MHz Memory up to 128GB
  • Supports up to 1 x double slot Accelerator cards
    - Standard model: Alveo U50 (Changeable to U25, U30, U200, U250 and U280 as an option)
  • PCIe Gen4 support
  • Total support 3 x M.2 slots and 5 x SATA ports
  • Tower Case with Thermaltake CPU Cooling Systems
  • Pre-installed and ready to use
    - Ubuntu 20.04 LTS Server
    - AMD Machine Learning Suite
    - AMD’s Vitis AI Docker container

TKAS-S2101 Specification

  • Dual 3rd Generation Altera (Intel)R Xeon Processor with Deep Learning Boost AI acceleration and AVX-512 instruction set
  • DDR4 memory up to 3TB
  • Supports up to 2 x double slot NVIDIA A100 Cards
  • PCIe Gen3 and Gen4 expansion slots
  • Support SATA/SAS/Gen4 NVMe Storage
  • Dual 2400W 80 PLUS Platinum redundant power supply
  • 2U Rack Server with NVIDIA validated platform
  • Pre-installed and ready to use upon request
* Features and specifications are planned and subject to change without notice.
