AB SeriesAdapter Boards for Gigabit IP core Evaluation
AB Series is Extension Adapter Boards for Giga bit IP core evaluation. AB Series
support AMD/Altera FPGA boards. By using AB Series, Giga bit IP cores work
on AMD/Altera FPGA boards.
| Part Number | Note | IP core | YouTube Video |
 AB20-U2PCI |
PCIe Gen5 SSD support, U.2/U.3-PCIe adapter board for NVMe-IP evaluation . Able to connect 4 U.2/U.3 NVMe SSDs. * SSDs are also available. Product manualPurchase from  |
 |
 |
 AB19-M2PCI |
PCIe Gen5 SSD support, M.2-PCIe adapter board for NVMe-IP evaluation . Able to connect 4 NVMe SSDs. * SSD is not included.Download manual Purchase from |
|
 |
 AB18-PCIeX16 |
PCIe x16 Lanes Crossover adapter board for NVMe-IP evaluationDownload manual Purchase from |
|
 AB Series Introduction |
 AB17-M2FMC |
M.2-FMC adapter board for NVMe-IP evaluation. Able to connect 2 NVMe SSDs. * SSD is not included.Download manual Purchase from |
|
|
 AB09-FMCRAID |
FMC-SATA(10ch) adapter board for SATA-IP with RAID evaluationDownload manual Product page Purchase from |
 |
|
|
|
|||
| Part Number | Note | FPGA Board | |
 AB01-PCIe2SATA |
PCIe-SATA(1ch) adapter board for SATA-IP evaluationDownload manual |
|
AMD SP605 |
 AB02-CROSSOVER |
SATA- SATA crossover board for SATA Device IP evaluationDownload manual |
|
- |
 AB03-SDCARD |
SD card adapter board for SD-IP evaluation | Please ask DG | |
 AB04-SDCARD |
SD card adapter board for SDXC-IP evaluation |  |
Please ask DG |
 AB05-PCIeSATAx8-PW |
PCIe-SATA(8ch) adapter board for SATA-IP with RAID evaluation (need external power) |
|
Please ask DG |
 AB06-PCIeSATAx8 |
PCIe-SATA(8ch) adapter board for SATA-IP with RAID evaluation (no need external power) |
|
Please ask DG |
 AB07-USB3FMC |
FMC extension board for USB3.0-IP. USB3.0 TypeA to A cable (1m) is containedDownload manual FMC I/O voltage is 2.5V only, does not support 1.8V I/O board such as VC707/VC709/KCU105. Purchase from |
 |
AMD SP605/ML605 KC705/ZC706 |
| AB07-USB3FMC-1.8VIF |
FMC extension board for USB3.0-IP. USB3.0 TypeA to A cable (1m) is contained. Support FMC I/O voltage 1.8V
only.Download manual FMC I/O voltage is 1.8V only. |
|
AMD VC707 |
 AB08-USB3HSMC |
HSMC extension board for USB3.0-IP. USB3.0 TypeA to A cable (1m) is containedDownload manual |
|
Altera StratixIV GX ArriaII GX ArriaV GX CycloneIV GX CycloneV E |
 AB10-PATAFMC |
FMC-PATA adapter board * coming soon |
Please ask DG | |
 AB11-HSMCSATA |
HSMC-SATA(1ch) adapter board for SATA-IP evaluationDownload manual |
|
* Discontinued. Please use AB12-HSMCRAID |
 AB12-HSMCRAID |
HSMC-SATA(8ch) adapter board for SATA-IP evaluationDownload manual |
|
Altera StratixV GX ArriaV GX StratixIV GX ArriaII GX CycloneIV GX |
 AB13-USB3PCIe |
USB3.0-PCIe adaptor board for evaluating USB3.0-IP(external PHY less). Able to connect up to 6 ch USB3.0.Download manual |
|
Please ask DG |
 AB14-CLKSMA |
SMA clock module for SATA-IP core evaluation for AC701 | |
AMD AC701 |
 AB15-SFPFMC |
SFP-FMC adapter board for TOE10G-IP evaluation 4ch SFP+ interfaces On board 312.5MHz Clock Oscillator Download manual |
 |
Please ask DG |
 AB16-PCIeXOVR |
PCIe Crossover adapter board for NVMe-IP evaluationDownload manual Purchase from |
|
Altera Arria V GX Arria 10 GX AMD ZCU106, KCU105, ZC706 VC707, VC709, KC705 |
